According to the 10 years experience of post installed anchoring, there is a formula for the amount of HM-500 injectable anchoring adhesive:
According to the 10 years experience of post installed anchoring, there is a formula for the amount of HM-500 injectable anchoring adhesive:
W=2/3*π*（D/2）2*L
It can be added to the workers' Consumption: 5-15%
W: amount of anchoring glue used for each anchor hole
D: hole diameter
L:hole depth
(Each anchoring adhesive is calculated by 390ML, and the specific gravity is 1.4-1.6 g/cm3 )
The table of using gule quantities of HM-500 epoxy anchor adhesive
the steel bar diameter | pore size | pore depth | the injecting glue volume | theoretic number | note |
| mm | mm | mm | ml(2/3v) | piece | |
| 8 | 12 | 80 | 6.03 | 64.67 | 10d |
| 8 | 12 | 120 | 9.04 | 43.14 | 15d |
| 8 | 12 | 160 | 12.06 | 32.33 | 20d |
| 10 | 14 | 100 | 10.26 | 38.01 | 10d |
| 10 | 14 | 150 | 15.08 | 25.86 | 15d |
| 10 | 14 | 200 | 20.52 | 19.01 | 20d |
| 12 | 16 | 120 | 16.09 | 24.23 | 10d |
| 12 | 16 | 180 | 24.12 | 16.16 | 15d |
| 12 | 16 | 240 | 32.18 | 12.11 | 20d |
| 14 | 18 | 140 | 23.73 | 16.43 | 10d |
| 14 | 18 | 210 | 35.61 | 10.95 | 15d |
| 14 | 18 | 280 | 47.46 | 8321 | 20d |
| 16 | 22 | 160 | 40.52 | 9.62 | 10d |
| 16 | 22 | 240 | 60.79 | 6.41 | 15d |
| 16 | 22 | 320 | 81.04 | 4.81 | 20d |
| 18 | 25 | 180 | 58.87 | 6.62 | 10d |
| 18 | 25 | 270 | 88.31 | 4.41 | 15d |
| 18 | 25 | 360 | 117.74 | 3.31 | 20d |
| 20 | 28 | 200 | 82.06 | 4.75 | 10d |
| 20 | 28 | 300 | 123.09 | 3.16 | 15d |
| 20 | 28 | 400 | 164.12 | 2.37 | 20d |
| 22 | 30 | 220 | 103.62 | 3.76 | 10d |
| 22 | 30 | 330 | 155.43 | 2.5 | 15d |
| 22 | 30 | 440 | 207.24 | 1.88 | 20d |
| 25 | 32 | 250 | 133.97 | 2.91 | 10d |
| 25 | 32 | 375 | 200.96 | 1.94 | 15d |
| 25 | 32 | 500 | 267.95 | 1.45 | 20d |
